Product Description


1. Adopt the anilox roller to spread ink.
2. Unwinding and rewinding are controlled by magnetic power brake, clutch, (or by automatic tension controller of mitsubishi, made in Japan).
3. Each printing unit adopt 360o for registration.
4. Each printing unit have one IR drier.
5. The rubber roller can break away automatically while parking, and running at a low speed, in order to avoid ink being dry.
6. The main motor is adopted the import stepless regulation of frequency conversion.
7. Unwinding, web guiding, corona discharging printing, IR drying and rewinding can be finished in one process, this is an ideal machine to print many kinds of paper cup.


Model SHR650-4 SHR850-4
Printing Speed 60m/min 60m/min
Printing Color 4 Colors 4 Colors
Max. Web Width 660mm 860mm
Max. Printing Width 650mm 850mm
Max. Printing Diameter 1400mm 1400mm
Max. Winding Diameter 1400mm 1400mm
Printing Girth 180-420mm 180-420mm
Registering precision 0.15mm 0.15mm
Thickness of paper 60-350gsm 60-350gsm
Dimensions(L*W*H) 3500x1650x2200mm 3500x1850x2200mm
Machine Weight About 3200kg About 3800kg
